6082
Cold Drawn/Finished (CF) / AlMgSi1 / AlSi1MgMn (Soğuk Çekim) / 6082 / T4
| Chemical Properties | % Value |
| Silicon (Si) | 0,70 - 1,30 |
| Chromium (Cr) | 0,00 - 0,25 |
| Manganese (Mn) | 0,40 - 1,00 |
| Magnesium (Mg) | 0,60 - 1,20 |
| Copper (Cu) | 0,00 - 0,10 |
| Titanium (Ti) | 0,00 - 0,10 |
| Iron (Fe) | 0,00 - 0,50 |
| Zinc (Zn) | 0,00 - 0,20 |
| Aluminium (Al) | Balance |
| Physical Properties | Value |
| Density | 2.71 g/cm³ |
| Melting Point | 575 °C |
| Thermal Expansion | 23.1 µm/m.°C |
| Modulus of Elasticity | 71 GPa |
| Thermal Conductivity | 170 W/m.K |
| Electrical Resistivity | 42% IACS |
| Mechanical Properties | Value |
| Proof Strength | 120 MPa |
| Yield Strength | 205 MPa |
| Shear Strength | 126 MPa |
| Elongation A50 mm | %16 |
| Hardness | 58 HB |
| 6082 T4 Temperature – Ultimate Tensile Strength Graph |
![]() |
| 6082 T4 Thickness – Ultimate Tensile Strength Graph |
![]() |
| 6082 T4 Diameter – Ultimate Tensile Strength Graph |
![]() |
6082 T4 aluminum alloy belongs to the Al-Mg-Si series and is an engineering material preferred especially in structural applications requiring medium to high strength. The T4 temper refers to the condition after solution heat treatment followed by natural aging, and this condition provides the alloy with good formability while offering sufficient mechanical strength. Compared to 6061, 6082 provides slightly higher strength, while it is significantly more durable than 6063.
In terms of corrosion resistance, 6082 T4 alloy performs quite well in marine and atmospheric environments. Thanks especially to its magnesium and silicon content, its
oxidation resistance is high. However, when compared to 5xxx series alloys (for example 5083), its resistance to saltwater is slightly lower. Nevertheless, it provides sufficient and reliable corrosion performance for general engineering applications.
In terms of mechanical strength and machinability, 6082 T4 presents a balanced profile. Although it shows lower strength compared to high-strength alloys such as 7075, it offers much better weldability and toughness. Its machinability is at a level similar to 6061 and provides stable results in machining operations. In addition, its vibration damping capacity is better than harder alloys; this provides an advantage in machinery and structural systems.
Forming and bending properties are quite good in the T4 temper. 6082 T4 can be bent much better compared to the T6 condition and has a low risk of cracking. For this reason, it is preferred in the production of parts with complex geometries. In terms of coating, it is suitable for anodizing processes, however its decorative surface quality may not be as good as 6063.
Applications reflect the versatility of 6082 T4 alloy. It is widely used in automotive, railway systems, bridge constructions, crane arms, machine parts and general structural applications. Compared to 6061, it is preferred in higher strength structural elements, offers better machinability than 5083, and stands out with much better weldability compared to 7075.
MATERIAL COMPOSITION STANDARDS
6082 T4 can be produced according to the following standards:
• 6082 T4 Plate; ISO AlSi1MgMn, ASTM B209, UNS A96082, WNR 3.2315
• 6082 T4 Sheet; ISO AlSi1MgMn, ASTM B209, UNS A96082, WNR 3.2315
• 6082 T4 Cold Drawn Bar; ISO AlSi1MgMn, ASTM B211, UNS A96082, WNR 3.2315
• 6082 T4 Cold Drawn Beam; ISO AlSi1MgMn, ASTM B211, UNS A96082, WNR 3.2315
• 6082 T4 Cold Drawn Wire; ISO AlSi1MgMn, ASTM B211, UNS A96082, WNR 3.2315
• 6082 T4 Cold Drawn Tube; ISO AlSi1MgMn, ASTM B211, UNS A96082, WNR 3.2315
• 6082 T4 Extruded Bar; ISO AlSi1MgMn, ASTM B221, UNS A96082, WNR 3.2315
• 6082 T4 Extruded Beam; ISO AlSi1MgMn, ASTM B221, UNS A96082, WNR 3.2315
• 6082 T4 Extruded Wire; ISO AlSi1MgMn, ASTM B221, UNS A96082, WNR 3.2315
• 6082 T4 Extruded Tube; ISO AlSi1MgMn, ASTM B221, UNS A96082, WNR 3.2315
CHARACTERISTIC PROPERTIES OF 6082 T4:
- Strength: Very Good
- Machinability: Good
- Weldability: Medium (T6 heat treatment is recommended.)
- Formability: Excellent
- Corrosion Resistance: Above Average
- Heat Treatment: Yes
COMMON APPLICATIONS OF 6082 T4:
Structural materials under high stress,
Marine and boat applications,
Also used in bicycle manufacturing and machinery industry.
STOCK
We supply 6082 T4 in plate/sheet, sheet, bar/beam, and tube/profile forms.
- Plate / Sheet
- Sheet
- Bar / Beam
- Tube / Profile
