7049

AMS 4159 / AlZn8MgCu / 7049 / T76511

Chemical Properties % Value
Silicon (Si)0,00 - 0,25
Chromium (Cr)0,10 - 0,22
Manganese (Mn)0,00 - 0,20
Magnesium (Mg)2,00 - 2,90
Copper (Cu)1,20 - 1,90
Titanium (Ti)0,00 - 0,10 / -
Iron (Fe)0,00 - 0,35
Zinc (Zn)7,20 - 8,20
Aluminium (Al)Balance
Physical Properties Value
Density2.84 g/cm³
Melting Point477 °C
Thermal Expansion23,4 x 10^-6 /K
Modulus of Elasticity71,7 GPa
Thermal Conductivity154 W/m.K
Mechanical Properties Value
Proof Strength520 MPa
Yield Strength450 MPa
Elongation A50 mm%9
Modulus of Elasticity72 GPa

Aluminium alloy 6082 is a medium strength alloy with excellent corrosion resistance. It has the highest strength of the 6000 series alloys. Alloy 6082 is known as a structural alloy. In plate form, 6082 is the alloy most commonly used for machining. As a relatively new alloy, the higher strength of 6082 has seen it replace 6061 in many applications. The addition of a large amount of manganese controls the grain structure which in turn results in a stronger alloy.
It is difficult to produce thin walled, complicated extrusion shapes in alloy 6082. The extruded surface finish is not as smooth as other similar strength alloys in the 6000 series.
In the T6 and T651 temper, alloy 6082 machines well and produces tight coils of swarf when chip breakers are used.

Applications
6082 is typically used in:
~ Highly stressed applications
~ Trusses
~ Bridges
~ Cranes
~ Transport applications
~ Ore skips
~ Beer barrels
~ Milk churns

ALLOY DESIGNATIONS

Aluminium alloy 6082 also corresponds to the following standard designations and specifications but may not be a direct equivalent:

AA6082

HE30

DIN 3.2315

EN AW-6082

ISO: Al Si1MgMn

A96082

TEMPER TYPES

The most common tempers for 6082 aluminium are:

  • T6 - Solution heat treated and artificially aged
  • O - Soft
  • T4 - Solution heat treated and naturaly aged to a substantially stable condition
  • T651 - Solution heat treated, stress relieved by stretching then artificially aged

SUPPLIED FORMS

Alloy 6082 is typically supplied as Channel, Angle, Tee, Square bar, Square box section, Rectangular box section, Flat bar, Tube and Sheet

Plate and shate can also be supplied as 6082-T651

  • Extrusions
  • Bar
  • Plate
  • Sheet
  • Tube

WELDABILITY

6082 has very good weldability but strength is lowered in the weld zone. When welded to itself, alloy 4043 wire is recommended. If welding 6082 to 7005, then the wire used should be alloy 5356.



Weldability – Gas: Good

Weldability – Arc: Good

Weldability – Resistance: Good

Brazability: Good

Solderability: Good

FABRICATION

Workability - Cold: Good

Machinability: Good
