5754 H16 aluminum alloy is a magnesium (Mg) containing alloy belonging to the 5xxx series in a strain-hardened (half hard) temper condition. This alloy stands out with its high corrosion resistance, medium-to-high strength, and good surface quality. The H16 temper provides higher strength than H22 while slightly reducing formability. It offers reliable performance in seawater, industrial atmospheres, and chemical environments.

In terms of strength, 5754 H16 provides higher strength than H111 and H22 tempers but lower than H32 and H34 tempers. Compared to 5052 H16 alloy, it offers similar strength levels but may provide better surface quality in some applications. When compared to 5083 alloy, it offers lower strength but better formability. Compared to 6061-T6 alloy, it has lower strength but significantly better corrosion resistance.

In terms of machinability, 5754 H16 alloy is moderate; it is not ideal for machining but is suitable for processing in sheet and plate form. Its bending capability is more limited than H22 and requires more careful forming. Due to higher strength, more force is required during forming operations.

In terms of coating capability, 5754 H16 performs well and is suitable for surface treatments such as painting and anodizing. It is preferred in decorative and visible applications due to its surface quality. In terms of vibration response, it offers good damping capacity and stable performance under dynamic loads.

Its weldability is very high and it can be easily welded using methods such as MIG and TIG. Some strength reductions may occur after welding, but overall performance remains stable. The 5754 H16 alloy is used in applications such as automotive parts, panels, marine applications, tanks, and general engineering applications. It stands out especially in applications requiring corrosion resistance, strength, and surface quality.

MATERIAL COMPOSITION STANDARDS

5754 H16 is available according to the following standards:
• 5754 H16 Sheet; ASTM B209, UNS A95754, WNR 3.3535, UNI AlMg3.5, UNE L-3390, AFNOR A-G3M


Key Characteristics of 5754 H16:

• Strength: Good
• Machinability: Above Average
• Weldability: Excellent
• Formability: Moderate
• Corrosion Resistance: Above Average
• Heat Treatment: No


Some Common Applications of 5754 H16:
In drilling towers,
Transportation equipment,
Also used in automotive body panels.


STOCK
We produce and supply 5754 H16 in sheet form.

• Sheet
