1060

AMS 4000 / Al99.6 / 1060 / O

Chemical Properties % Value
Silicon (Si)0,00 - 0,25
Manganese (Mn)0,00 - 0,03
Magnesium (Mg)0,00 - 0,03
Copper (Cu)0,00 - 0,03
Titanium (Ti)0,00 - 0,03
Iron (Fe)0,00 - 0,35
Zinc (Zn)0,00 - 0,05
Aluminium (Al)Balance
Physical Properties Value
Density2.705 g/cm³
Melting Point646.1 °C
Thermal Expansion25.5 x 10^-6 /K
Modulus of Elasticity73 GPa
Thermal Conductivity155 W/m.K
Electrical Resistivity%40 IACS
Mechanical Properties Value
Proof Strength18 MPa
Yield Strength75 MPa
Shear Strength48 MPa
Elongation A50 mm%43
Modulus of Elasticity69 MPa

1060 aluminum alloy is an aluminum-based alloy in the "commercially pure" wrought family. As a wrought alloy, it is typically formed by extrusion or rolling. It is commonly used in the electrical and chemical industries, on account of having high electrical conductivity, corrosion resistance, and workability.



ALLOY DESIGNATIONS

Aluminium alloy 1060, BS 1B has s imilarities to the following standard designations and specifications ;

AA 1060, AMS 4000

ISO Al99.6



TEMPER TYPES

The most common tempers for 1060 aluminium are:

  • O - Soft
  • H14 - Strain-hardened - 1/2 hard.



SUPPLIED FORMS

1060 aluminium is supplied in in plate and sheet.

  • Plate
  • Sheet
