5083
ASTM B221 / AlMg4.5Mn0.7 / 5083 / H111
| Chemical Properties | % Value |
| Silicon (Si) | 0,00 - 0,40 |
| Chromium (Cr) | 0,05 - 0,25 |
| Magnesium (Mg) | 4,00 - 4,90 |
| Copper (Cu) | 0,00 - 0,10 |
| Titanium (Ti) | 0,00 - 0,15 |
| Iron (Fe) | 0,00 - 0,40 |
| Zinc (Zn) | 0,00 - 0,25 |
| Aluminium (Al) | Balance |
| Manganese (Mn) | 0,40 - 1,00 |
| Physical Properties | Value |
| Density | 2.66 g/cm³ |
| Melting Point | 574 °C |
| Thermal Expansion | 23.9 µm/m.°C |
| Modulus of Elasticity | 68 GPa |
| Thermal Conductivity | 121 W/m.K |
| Electrical Resistivity | 29% IACS |
| Mechanical Properties | Value |
| Proof Strength | 150 MPa |
| Yield Strength | 310 MPa |
| Shear Strength | 180 MPa |
| Elongation A50 mm | 13% |
| Hardness | 75 HB |
5083 H111 aluminum plate also retains exceptional strength after welding. It has the highest strength of the non-heat treatable alloys but is not recommended for use in temperatures in excess of 65°C.
ALLOY DESIGNATIONS
5083 H111 has the following standard designations and specifications.
Extruded Round/Flat Bar, Wires and Tubes per: 5083 H111, ASTM B221, UNS A95083, ASTM B928, WNR 3.3547, AMS QQ-A-200/4, ISO AlMg4.5Mn0.7, DIN AlMg4.5Mn
Sheets and Plates per; 5083 H111, ASTM B209, UNS A95083, WNR 3.3547, AMS QQ-A-250/6, DIN AlMg4.5Mn, ISO AlMg4.5Mn0.7
Choosing Factors for 5083 H111
- Strength: Very good
- Machining: Weak
- Weldability: Good
- Formability: Moderate
- Corrosion Resistance: Very good
- Heat Treating: No
Some Well-Known Applications for 5083 H111
In the interiors of ships,
In fuel tanks,
It is also used in railway vagons.
SUPPLIED FORMS
5083 H111 is produced/supplied in plate/sheet, round/flat bar and tube/profile forms.
- Plate
- Sheet
- Rod / Round Bar / Flat Bar
- Tube/Profile
