6061
AMS 4150 / AlMg1SiCu / 6061 / T6
| Chemical Properties | % Value |
| Silicon (Si) | 0,40 - 0,80 |
| Chromium (Cr) | 0,04 - 0,35 |
| Manganese (Mn) | 0,00 - 0,15 |
| Magnesium (Mg) | 0,80 - 1,20 |
| Copper (Cu) | 0,15 - 0,40 |
| Titanium (Ti) | 0,00 - 0,15 |
| Iron (Fe) | 0,00 - 0,70 |
| Zinc (Zn) | 0,00 - 0,25 |
| Aluminium (Al) | Balance |
| Physical Properties | Value |
| Density | 2.70 g/cm³ |
| Melting Point | 582 °C |
| Thermal Expansion | 23.6 µm/m.°C |
| Modulus of Elasticity | 69 GPa |
| Thermal Conductivity | 167 W/m.K |
| Electrical Resistivity | %43 IACS |
| Mechanical Properties | Value |
| Proof Strength | 276 MPa |
| Yield Strength | 310 MPa |
| Shear Strength | 207 MPa |
| Elongation A50 mm | 15% |
| Hardness | 95 HB |
6061 T6 aluminum exhibits mid strength and is widely used in aerospace applications.
ALLOY DESIGNATIONS
6061 T6 has the following standard designations and specifications.
As Plate/Sheet; 6061 T6, AMS 4027, AMS QQ-A-250/11, EN 2694, AIR 9048.240, UNS A96061, WNR 3.3211, ASTM B209
As Cold Drawn Round/Flat Bar and Tube; 6061 T6, AMS 4117, AMS QQ-A-225/8, EN 2392, BS L117, UNS A96061, WNR 3.3211, ASTM B211
As Seamless Cold Drawn Round/Flat Bar and Tube; 6061 T6, AMS 4082, AMS 4083 (Hydraulic Tube), WW-T-700/6, MIL-T-7081 (Hydraulic Tube), UNS A96061, WNR 3.3211, ASTM B241
As Extruded Round/Flat Bar and Tube; 6061 T6, AMS 4113, AMS 4127, AMS 4150, AMS QQ-A-200/16 (Structural shapes), AMS QQ-A-200/8, UNS A96061, WNR 3.3211, ASTM B221
Choosing Factors for 6061 T6
- Strength: Mediocre
- Machining: Okay
- Weldability: Excellent
- Formability: Good
- Corrosion Resistance: Great
- Heat Treating: Yes
Some Well-Known Applications for 6061 T6
In pipelines, tank parts,
In the structure of durable consumer goods,
It has many uses, including in motor boats.
SUPPLIED FORMS
6061 T6 is produced/supplied in plate/sheet round/flat bar and tube/profile forms.
- Rod / Round Bar / Flat Bar
- Plate
- Sheet
- Tube/Profile
DELIVERY:
| Mechanical Properties | |||
| Thickness (mm) | Proof Strength (Min.) | Yield Strength (Min.) | Elongation A50 mm % |
| Over 0.2 up to & incl. 0.5 | 241 | 290 | %8 |
| Over 0.5 up to & incl. 6.5 | 241 | 290 | %10 |
