6061
Cold Drawn/Finished (CF) / AlMg1SiCu (Soğuk Çekim) / 6061 / T4
| Chemical Properties | % Value |
| Silicon (Si) | 0,00 - 0,25 |
| Chromium (Cr) | 0,15 - 0,35 |
| Manganese (Mn) | 0,00 - 0,10 |
| Magnesium (Mg) | 2,20 - 2,80 |
| Copper (Cu) | 0,00 - 0,10 |
| Iron (Fe) | 0,00 - 0,40 |
| Zinc (Zn) | 0,00 - 0,10 |
| Aluminium (Al) | Balance |
| Physical Properties | Value |
| Density | 2.70 g/cm³ |
| Melting Point | 582 °C |
| Thermal Expansion | 23.8 µm/m.°C |
| Modulus of Elasticity | 70 GPa |
| Thermal Conductivity | 140 W/m.K |
| Electrical Resistivity | %35 IACS |
| Mechanical Properties | Value |
| Proof Strength | 180 MPa |
| Yield Strength | 240 MPa |
| Shear Strength | 170 MPa |
| Elongation A50 mm | %13 |
| Hardness | 65 HB |
The cold-drawn 6061 T4 aluminum alloy is known for its excellent machinability, high corrosion resistance, and good mechanical properties. It is widely used in industries such as automotive, aerospace, construction, and machinery manufacturing, particularly in applications that require structural components with strength and durability. The 6061 T4 alloy is suitable for anodizing, which not only enhances its aesthetic appearance but also improves surface hardness and overall durability.
In terms of weldability, 6061 T4 performs very well, making it ideal for welding processes such as Metal Inert Gas (MIG) welding and Tungsten Inert Gas (TIG) welding. Its good bending properties allow it to be easily shaped into various forms, adding to its versatility. The alloy also performs well in high-vibration environments, making it a reliable choice for dynamic applications such as automotive and aerospace industries. Its corrosion resistance ensures long-lasting performance in harsh environments, including marine and outdoor applications.
The advantages of 6061 T4 aluminum alloy include excellent machinability, high corrosion resistance, and ease of welding. However, its drawbacks include slightly lower strength compared to other aluminum alloys and potential performance loss at high temperatures. Despite these limitations, 6061 T4 remains a versatile and widely used material due to its overall balance of properties.
As Plate/Sheet; 6061 T4, AMS 4026, EN 3341, AIR 9048.220, UNS A96061, WNR 3.3211, ISO AlMg1SiCu, ASTM B209
As Extruded Round/Flat Bar, Wire,Tube and Forgings: 6061 T4, AMS 4166 (Forgings), AMS 4161, EN 3342, UNS A96061, WNR 3.3211, ISO AlMg1SiCu, ASTM B221
As Cold Drawn Round/Flat Bar, Wire and Tube; 6061 T4, AMS 4116, EN 3557, UNS A96061, WNR 3.3211, ISO AlMg1SiCu, ASTM B211
As Seamless Cold Drawn Round/Flat Bar, Wire and Tube; 6061 T4, AMS 4081, UNS A96061, WNR 3.3211, ISO AlMg1SiCu, ASTM B241
Choosing Factors for 6061 T4
- Strength: Mediocre
- Machining: Okay
- Weldability: Perfect
- Formability: Good
- Corrosion Resistance: Very good
- Heat Treating: Yes
Some Well-Known Applications for 6061 T4
As a component of electric poles, furniture parts,
Applications requiring high pressure in the aerospace and transportation industry,
It is also used in helicopter parts.
- Rod / Round Bar / Flat Bar
- Plate
- Sheet
- Tube/Profile
