6063
ASTM B221 / AlMg0.7Si / 6063 / T5
| Chemical Properties | % Value |
| Silicon (Si) | 0,20 - 0,60 |
| Chromium (Cr) | 0,00 - 0,10 |
| Manganese (Mn) | 0,00 - 0,10 |
| Magnesium (Mg) | 0,45 - 0,90 |
| Copper (Cu) | 0,00 - 0,10 |
| Titanium (Ti) | 0,00 - 0,10 |
| Iron (Fe) | 0,00 - 0,35 |
| Zinc (Zn) | 0,00 - 0,10 |
| Aluminium (Al) | Balance |
| Physical Properties | Value |
| Density | 2.70 g/cm³ |
| Melting Point | 616 °C |
| Thermal Expansion | 23.4 µm/m.°C |
| Modulus of Elasticity | 69 GPa |
| Thermal Conductivity | 210 W/m.K |
| Electrical Resistivity | %53 IACS |
| Mechanical Properties | Value |
| Proof Strength | 145 MPa |
| Yield Strength | 186 MPa |
| Shear Strength | 117 MPa |
| Elongation A50 mm | 12% |
| Hardness | 60 HB |
6063 T5 aluminum exhibits mid strength and is widely used in aerospace applications.
ALLOY DESIGNATIONS
6063 T5 has the following standard designations and specifications.
As Extruded Round/Flat Bar and Tube; 6063 T5, AMS QQ-A-200/9, ASTM B221 , ASTM B429, UNS A96063, DIN AlMgSi0,5
Choosing Factors for 6063 T5
- Strength: Average
- Machining: Good
- Weldability: Great
- Formability: Okay
- Corrosion Resistance: Excellent
- Heat Treating: Yes
Some Well-Known Applications for 6063 T5
In architectural applications such as door and window frames,
In stair and radiator systems and in assembly components.
It is also used in pneuromatic installations and highly in extrusion systems.
SUPPLIED FORMS
6063 T5 is produced/supplied in round/flat bar and tube/profile forms.
- Rod / Round Bar / Flat Bar
- Tube/Profile
