6066
AMS QQ-A-200/10 / AlMg0.7Si / 6066 / T6
| Chemical Properties | % Value |
| Silicon (Si) | 0,90 - 1,80 |
| Chromium (Cr) | 0,00 - 0,40 |
| Manganese (Mn) | 0,60 - 1,10 |
| Magnesium (Mg) | 0,80 - 1,40 |
| Copper (Cu) | 0,70 - 1,20 |
| Titanium (Ti) | 0,00 - 0,20 |
| Iron (Fe) | 0,00 - 0,50 |
| Zinc (Zn) | 0,00 - 0,25 |
| Aluminium (Al) | Balance |
| Physical Properties | Value |
| Density | 2,72 g/cm³ |
| Melting Point | 563 °C |
| Thermal Expansion | 23.2 µm/m.°C |
| Modulus of Elasticity | 71 GPa |
| Thermal Conductivity | 147 W/m.K |
| Electrical Resistivity | 40% IACS |
| Mechanical Properties | Value |
| Proof Strength | 350 MPa |
| Yield Strength | 393 MPa |
| Shear Strength | 240 MPa |
| Elongation A50 mm | 12% |
| Hardness | 120 HB |
6066 T6 aluminum exhibits high strength and is widely used in aerospace applications.
ALLOY DESIGNATIONS
6066 T6 has the following standard designations and specifications.
As Extruded Round/Flat Bar and Tube; 6066 T6, AMS QQ-A-200/10, ASTM B221, UNS A96066, ISO AlMg0.7Si
As Cold Drawn Round/Flat Bar and Tube: 6066 T6, ASTM B211, UNS A96066, ISO AlMg0.7Si
Choosing Factors for 6066 T6
- Strength: Great
- Machining: Fair
- Weldability: Mediocre
- Formability: Very good
- Corrosion Resistance: Very good
- Heat Treating: Yes
Some Well-Known Applications for 6066 T6
As components of interior elements, rails,
In radiators and heat exchangers,
It is used in many areas, including office furniture parts.
SUPPLIED FORMS
6066 T6 is produced/supplied in round/flat bar and tube/profile forms.
- Rod / Round Bar / Flat Bar
- Tube/Profile
