6262
AMS QQ-A-225/10 / AlMg1SiPb / 6262 / T9
| Chemical Properties | % Value |
| Silicon (Si) | 0,40 - 0,80 |
| Chromium (Cr) | 0,04 - 0,14 |
| Manganese (Mn) | 0,00 - 0,15 |
| Magnesium (Mg) | 0,80 - 1,20 |
| Copper (Cu) | 0,15 - 0,40 |
| Titanium (Ti) | 0,00 - 0,15 |
| Iron (Fe) | 0,00 - 0,70 |
| Zinc (Zn) | 0,00 - 0,25 |
| Aluminium (Al) | Balance |
| Physical Properties | Value |
| Density | 2,72 g/cm³ |
| Melting Point | 582 °C |
| Thermal Expansion | 22.8 µm/m.°C |
| Modulus of Elasticity | 68 GPa |
| Thermal Conductivity | 170 W/m.K |
| Electrical Resistivity | %44 IACS |
| Mechanical Properties | Value |
| Proof Strength | 379 MPa |
| Yield Strength | 400 MPa |
| Shear Strength | 241 MPa |
| Elongation A50 mm | %6 |
| Hardness | 120 HB |
6262 T9 aluminum exhibits high strength and is widely used in aerospace applications.
ALLOY DESIGNATIONS
6262 T9 has the following standard designations and specifications.
As Cold Drawn Round/Flat Bar and Tube: 6262 T9, AMS QQ-A-2225/10, ASTM B211, UNS A96262, ISO AlMg1SiPb, ASTM B483
Choosing Factors for 6262 T9
- Strength: Great
- Machining: Good
- Weldability: Good
- Formability: Poor
- Corrosion Resistance: Excellent
- Heat Treating: Yes
Some Well-Known Applications for 6262 T9
As camera parts, fasteners,
In knobs and decorative hardware,
It has many areas of use, including in the machinery industry.
SUPPLIED FORMS
6262 T9 is produced/supplied in round/flat bar and tube/profile forms.
- Rod / Round Bar / Flat Bar
- Tube/Profile
