7049
AMS 4159 / AlZn8MgCu / 7049 / T76511
| Chemical Properties | % Value |
| Silicon (Si) | 0,00 - 0,25 |
| Chromium (Cr) | 0,10 - 0,22 |
| Manganese (Mn) | 0,00 - 0,20 |
| Magnesium (Mg) | 2,00 - 2,90 |
| Copper (Cu) | 1,20 - 1,90 |
| Titanium (Ti) | 0,00 - 0,10 / - |
| Iron (Fe) | 0,00 - 0,35 |
| Zinc (Zn) | 7,20 - 8,20 |
| Aluminium (Al) | Balance |
| Physical Properties | Value |
| Density | 2.84 g/cm³ |
| Melting Point | 477 °C |
| Thermal Expansion | 23,4 x 10^-6 /K |
| Modulus of Elasticity | 71,7 GPa |
| Thermal Conductivity | 154 W/m.K |
| Mechanical Properties | Value |
| Proof Strength | 520 MPa |
| Yield Strength | 460 MPa |
| Shear Strength | 410 MPa |
| Elongation A50 mm | %8 |
| Hardness | 150 HB |
7049 T76511 aluminum exhibits high strength and is widely used in aerospace applications.
ALLOY DESIGNATIONS
7049 T76511 has the following standard designations and specifications.
Extruded round/flat bars and tubes per; 7049 T76511, AMS 4159, ASTM B221, ISO AlZn8MgCu, AFNOR A-Z8GU, UNS A97049
Choosing Factors for 7049 T76511
- Strength: High
- Machining: Good
- Weldability: Low
- Formability: Moderate
- Corrosion Resistance: Very good
- Heat Treating: Yes
Some Well-Known Applications for 7049 T76511
Structural components of aircrafts,
In ammunitions parts and missile parts,
It is also used in mechanical-chemical industry.
SUPPLIED FORMS
7049 T76511 is produced/supplied in the round/flat bar and tube/profile form.
- Round/Flat Bar
- Tube/Profile
