7175
AMS 4344 / AlZn5.5MgCu(B) / 7175 / T73511
| Chemical Properties | % Value |
| Silicon (Si) | 0,00 - 0,15 |
| Tin (Sn) | 0,00 - 0,00 |
| Chromium (Cr) | 0,18 - 0,28 |
| Manganese (Mn) | 0,00 - 0,10 |
| Magnesium (Mg) | 2,10 - 2,90 |
| Copper (Cu) | 1,20 - 2,00 |
| Lead (Pb) | 0,00 - 0,00 |
| Titanium (Ti) | 0,08 - 0,21 |
| Iron (Fe) | 0,00 - 0,20 |
| Zinc (Zn) | 5,10 - 6,10 |
| Nickel (Ni) | 0,00 - 0,00 |
| Aluminium (Al) | Balance |
| Physical Properties | Value |
| Density | 2,80 g/cm³ |
| Melting Point | 477 °C |
| Thermal Expansion | 23.4 µm/m.°C |
| Modulus of Elasticity | 72 GPa |
| Thermal Conductivity | 140 W/m.K |
| Electrical Resistivity | 33 % IACS |
| Mechanical Properties | Value |
| Proof Strength | 435 MPa |
| Yield Strength | 505 MPa |
| Shear Strength | 300 MPa |
| Elongation A50 mm | 13% |
| Hardness | 145 HB |
7175 T73511 aluminum exhibits high strength and is widely used in aerospace applications.
ALLOY DESIGNATIONS
7175 T73511 has the following standard designations and specifications.
Extruded Round/Flat Bar and Tubes per; 7175 T73511, EN 4293, ASTM B221, ISO AlZn5.5MgCu(B), WNR 3.4334, AMS 4344
Choosing Factors for 7175 T73511
- Strength: Excellent
- Machining: Good
- Weldability: Poor
- Formability: Moderate
- Corrosion Resistance: Okay
- Heat Treating: Yes
Some Well-Known Applications for 7175 T73511
In aerospace parts that must withstand high temperatures and strength,
As components of machined fittings in aircrafts,
Along with the aerospace industry it is also used in the automotive sector.
SUPPLIED FORMS
7175 T73511 is produced/supplied in round/flat bar and tube/profile form.
- Round/Flat Bar
- Tube/Profile
