5086
AMS QQ-A-200/5 / AlMg4 / 5086 / O
| Chemical Properties | % Value |
| Silicon (Si) | 0,00 - 0,40 |
| Chromium (Cr) | 0,05 - 0,25 |
| Manganese (Mn) | 0,20 - 0,70 |
| Magnesium (Mg) | 3,50 - 4,50 |
| Copper (Cu) | 0,00 - 0,10 |
| Titanium (Ti) | 0,00 - 0,15 |
| Iron (Fe) | 0,00 - 0,50 |
| Zinc (Zn) | 0,00 - 0,25 |
| Aluminium (Al) | Balance |
| Physical Properties | Value |
| Density | 2,66 g/cm³ |
| Melting Point | 585 °C |
| Thermal Expansion | 23.8 µm/m.°C |
| Modulus of Elasticity | 71 GPa |
| Thermal Conductivity | 125 W/m.K |
| Electrical Resistivity | 29% IACS |
| Mechanical Properties | Value |
| Proof Strength | 117 MPa |
| Yield Strength | 262 MPa |
| Shear Strength | 159 MPa |
| Elongation A50 mm | 16% |
| Hardness | 70 HB |
5086 aluminum exhibits higher strength than 5052 and has excellent corrosion resistance in marine and salt water environments. It is easy to form, stamp and weld.
ALLOY DESIGNATIONS
5086 O has the following standard designations and specifications.
As Plate/Sheet; 5086 O, AMS QQ-A-250/7, ASTM B209, ISO AlMg4, DIN AlMg4Mn UNS A95086, ASTM B632, ASTM B928, AMS QQ-A-250/19, WNR 3.354
As Extrusion Rod, Flat Bar, Wire; 5086 O, ASTM B221, UNS A95086, ASTM B928, WNR 3.3545, AMS QQ-A-200/5
As Extruded Seamless Tube: 5086 O, WWW-T-700/5, ISO AlMg4, DIN AlMg4Mn UNS A95086, ASTM B241, WNR 3.3545
Choosing Factors for 5086 O
- Strength: Very good
- Machining: Good
- Weldability: Excellent
- Formability: Good
- Corrosion Resistance: Very good
- Heat Treating: Yes
Some Well-Known Applications for 5086 O
As a structural component of ship bridges and boats
As marine materials component,
In applications against corrosion,
It is used in TV and communication towers and in the defense industry.
SUPPLIED FORMS
5086 O is produced/supplied in plate/sheet, round/flat bar and tube/profile forms.
- Plate
- Sheet
- Rod / Round Bar / Flat Bar
- Tube/Profile
