6063
AMS 4156 / AlMg0.7Si / 6063 / T6
| Chemical Properties | % Value |
| Silicon (Si) | 0,20 - 0,60 |
| Chromium (Cr) | 0,00 - 0,10 |
| Manganese (Mn) | 0,00 - 0,10 |
| Magnesium (Mg) | 0,45 - 0,90 |
| Copper (Cu) | 0,00 - 0,10 |
| Titanium (Ti) | 0,00 - 0,10 |
| Iron (Fe) | 0,00 - 0,35 |
| Zinc (Zn) | 0,00 - 0,10 |
| Aluminium (Al) | Balance |
| Physical Properties | Value |
| Density | 2.70 g/cm³ |
| Melting Point | 616 °C |
| Thermal Expansion | 23.4 µm/m.°C |
| Modulus of Elasticity | 69 GPa |
| Thermal Conductivity | 200 W/m.K |
| Electrical Resistivity | 53% IACS |
| Mechanical Properties | Value |
| Proof Strength | 220 MPa |
| Yield Strength | 250 MPa |
| Shear Strength | 152 MPa |
| Elongation A50 mm | 17% |
| Hardness | 73 HB |
6063 T6 aluminum exhibits mid strength and is widely used in aerospace applications.
ALLOY DESIGNATIONS
6063 T6 has the following standard designations and specifications.
As Sheet/Plate; 6063 T6, ASTM B209, MIL-P-25995, UNS A96063, ISO AlMg0.7Si
As Extruded Seamless Tube;6063 T6, AMS QQ-A-200/9, ASTM B345, ASTM B241, ISO AlMg0.7Si
As Extruded Round/Flat Bar; 6063 T6, AMS QQ-A-200/9, AMS 4156, ASTM B221 , ASTM B429, ISO AlMg0.7Si, DTD 372B
As Cold Drawn Round/Flat Bar: 6063 T6, ASTM B483, ASTM B211, WNR 3.32206, ISO AlMg0.7Si
Choosing Factors for 6063 T6
- Strength: Mediocre
- Machining: Good
- Weldability: Very good
- Formability: Okay
- Corrosion Resistance: Great
- Heat Treating: Yes
Some Well-Known Applications for 6063 T6
In many architectural applications,
As a component of shop fittings
It is also used in special machine systems and as components of office furniture.
SUPPLIED FORMS
6063 T6 is produced/supplied in sheet/plate, round/flat bar and tube/profile forms.
- Sheet
- Plate
- Rod / Round Bar / Flat Bar
- Tube/Profile
