7079
AMS 4024 / AlZn4Mg3Cu / 7079 / T651
| Chemical Properties | % Value |
| Silicon (Si) | 0,00 - 0,30 |
| Chromium (Cr) | 0,10 - 0,25 |
| Manganese (Mn) | 0,10 - 0,30 |
| Magnesium (Mg) | 2,90 - 3,70 |
| Copper (Cu) | 0,40 - 0,80 |
| Titanium (Ti) | 0,00 - 0,10 |
| Iron (Fe) | 0,00 - 0,40 |
| Zinc (Zn) | 3,80 - 4,80 |
| Aluminium (Al) | Balance |
| Physical Properties | Value |
| Density | 2.81 g/cm³ |
| Melting Point | 635 °C |
| Thermal Expansion | 23.5 x 10^-6 /K |
| Modulus of Elasticity | 72 GPa |
| Thermal Conductivity | 134-160 W/m.K |
| Electrical Resistivity | %40 IACS |
| Mechanical Properties | Value |
| Proof Strength | 448 MPa |
| Yield Strength | 558 MPa |
| Shear Strength | 360 MPa |
| Elongation A50 mm | 11% |
| Hardness | 150 HB |
7079 T651 aluminum exhibits mid strength and is widely used in aerospace applications.
ALLOY DESIGNATIONS
7079 T651 has the following standard designations and specifications.
Plates per; 7079 T651, ASTM B209, AMS 4024, UNS A97079, ISO AlZn4Mg3Cu
Choosing Factors for 7079 T651
- Strength: Excellent
- Machining: Good
- Weldability: Poor
- Formability: Average
- Corrosion Resistance: Good
- Heat Treating: Yes
Some Well-Known Applications for 7079 T651
In the mobile industry equipments,
As a component of hydraulic power units,
It is also used in aircraft wings and fuselages.
SUPPLIED FORMS
7079 T651 is produced/supplied in the plate form.
- Plate
