6262
UNS A96262 / AlMg1SiPb / 6262 / T651
| Chemical Properties | % Value |
| Silicon (Si) | 0,40 - 0,80 |
| Chromium (Cr) | 0,04 - 0,14 |
| Manganese (Mn) | 0,00 - 0,15 |
| Magnesium (Mg) | 0,80 - 1,20 |
| Copper (Cu) | 0,15 - 0,40 |
| Titanium (Ti) | 0,00 - 0,15 |
| Iron (Fe) | 0,00 - 0,70 |
| Zinc (Zn) | 0,00 - 0,25 |
| Aluminium (Al) | Balance |
| Physical Properties | Value |
| Density | 2,72 g/cm³ |
| Melting Point | 582 °C |
| Thermal Expansion | 21.8 x 10^-6 /K |
| Modulus of Elasticity | 69 GPa |
| Thermal Conductivity | 170 W/m.K |
| Electrical Resistivity | %44 IACS |
| Mechanical Properties | Value |
| Proof Strength | 270 MPa |
| Yield Strength | 320 MPa |
| Shear Strength | 190 MPa |
| Elongation A50 mm | 6% |
| Hardness | 95 HB |
6262 T651 aluminum exhibits high strength and is widely used in aerospace applications.
ALLOY DESIGNATIONS
6262 T651 has the following standard designations and specifications.
As Extruded Round/Flat Bar and Tube: 6262 T651, ASTM B221, UNS A96262, ISO AlMg1SiPb
As Seamless Extruded Round/Flat Bar and Tube: 6262 T651, ASTM B241, USN A96262, ISO AlMg1SiPb
Choosing Factors for 6262 T651
- Strength: Excellent
- Machining: Okay
- Weldability: Good
- Formability: Weak
- Corrosion Resistance: Excellent
- Heat Treating: Yes
Some Well-Known Applications for 6262 T651
Appliance and oil line fittings,
In screw machines and camera parts,
It has a diverse range of uses, from hinges and door handles to manifolds.
SUPPLIED FORMS
6262 T651 is produced/supplied in round/flat bar and tube/profile forms.
- Rod / Round Bar / Flat Bar
- Tube/Profile
