AS 9120
6063
ASTM B429 / AlMg0.7Si / 6063 / T52
| Chemical Properties | % Value |
| Silicon (Si) | 0,20 - 0,60 |
| Chromium (Cr) | 0,00 - 0,10 |
| Manganese (Mn) | 0,00 - 0,10 |
| Magnesium (Mg) | 0,45 - 0,90 |
| Copper (Cu) | 0,00 - 0,10 |
| Titanium (Ti) | 0,00 - 0,10 |
| Iron (Fe) | 0,00 - 0,35 |
| Zinc (Zn) | 0,00 - 0,10 |
| Aluminium (Al) | Balance |
| Physical Properties | Value |
| Density | 2,69 g/cm³ |
| Melting Point | 616 °C |
| Thermal Expansion | 23.4 µm/m.°C |
| Modulus of Elasticity | 69 GPa |
| Thermal Conductivity | 200 W/m.K |
| Electrical Resistivity | 53% IACS |
| Mechanical Properties | Value |
| Proof Strength | 140 MPa |
| Yield Strength | 180 MPa |
| Shear Strength | 100 MPa |
| Elongation A50 mm | 8% |
| Hardness | 65 HB |
6063 T52 aluminum exhibits mid strength and is widely used in aerospace applications.
ALLOY DESIGNATIONS
6063 T52 has the following standard designations and specifications;
As Extruded Round/Flat Bar; 6063 T52, AMS QQ-A-200/9, ASTM B221 , ASTM B429, UNS A96063, DIN AlMgSi0,5
Choosing Factors for 6063 T52
- Strength: Average
- Machining: Good
- Weldability: Very good
- Formability: Good
- Corrosion Resistance: Excellent
- Heat Treating: Yes
Some Well-Known Applications for 6063 T52
Irrigation tubing
Structural cages and interior fittings
Doors, stair rails and also has a lot of applications in architecture.
SUPPLIED FORMS
6063 T52 is produced/supplied in round/flat bar and tube/profile forms.
- Sheet
- Rod / Round Bar / Flat Bar
- Tube/Profile
DELIVERY:
