5086
ASTM B209 / AlMg4 / 5086 / H321
化学性质 | % 值 |
Silicon (Si) | 0,00 - 0,40 |
Chromium (Cr) | 0,05 - 0,25 |
Magnesium (Mg) | 3,50 - 4,50 |
Manganese (Mn) | 0,20 - 0,70 |
Titanium (Ti) | 0,00 - 0,15 / - |
Iron (Fe) | 0,00 - 0,50 |
Zinc (Zn) | 0,00 - 0,25 |
Aluminium (Al) | Balance |
物理特性 | 值 |
Density | 2,66 g/cm³ |
Melting Point | 585 °C |
Thermal Expansion | 23.8 µm/m.°C |
Modulus of Elasticity | 68 GPa |
Thermal Conductivity | 130 W/m.K |
Electrical Resistivity | 31% IACS |
机械性能 | 值 |
Proof Strength | 220 MPa |
Yield Strength | 310 MPa |
Shear Strength | 190 MPa |
Elongation A50 mm | 16% |
Hardness | 85 HB |
ALLOY DESIGNATIONS
5086 H321 has the following standard designations and specifications.
As Plate/Sheet; 5086 H321, AMS QQ-A-250/7, ASTM B209, ISO AlMg4, DIN AlMg4Mn UNS A95086, ASTM B632, ASTM B928, AMS QQ-A-250/19, WNR 3.3545
Choosing Factors for 5086 H321
- Strength: Good
- Machining: Fairly good
- Weldability: Okay
- Formability: Very Good
- Corrosion Resistance: Excellent
- Heat Treating: Yes
Some Well-Known Applications for 5086 H321
Especially in maritime and marine and boat materials.
As a structural component of missiles,
It is also preferred in radio towers, armor plating and tank components.
SUPPLIED FORMS
5086 H321 is produced/supplied in plate/sheet forms.
- Plate
- Sheet
