5005
EN AW / AlMg1 / 5005 / H111
| 化学性质 | % 值 |
| Silicon (Si) | 0,00 - 0,30 |
| Chromium (Cr) | 0,00 - 0,10 |
| Manganese (Mn) | 0,00 - 0,20 |
| Magnesium (Mg) | 0,50 - 1,10 |
| Copper (Cu) | 0,00 - 0,20 |
| Iron (Fe) | 0,00 - 0,70 |
| Zinc (Zn) | 0,00 - 0,25 |
| Aluminium (Al) | Balance |
| 物理特性 | 值 |
| Density | 2.68 g/cm³ |
| Melting Point | 607 °C |
| Thermal Expansion | 23.7 µm/m.°C |
| Modulus of Elasticity | 68 GPa |
| Thermal Conductivity | 200 W/m.K |
| Electrical Resistivity | 52% IACS |
| 机械性能 | 值 |
| Proof Strength | 41.4 MPa |
| Yield Strength | 124 MPa |
| Shear Strength | 75 MPa |
| Elongation A50 mm | 7% |
| Hardness | 28 HB |
5005 H1111 has excellent finishing qualities and anodized coatings. Weldability is very good and 5005 H111 has good resistance to corrosion, especially when anodised. Alloy 5005 H111 sheet's typical uses are also included below.
ALLOY DESIGNATIONS
5005 H111 has the following standard designations and specifications.
Sheets per; 5005 H111, ISO AlMg1, DIN AlMg1, WNR 3.3315, UNS A95005, ASTM B209, BS N41
Cold Drawn Round/Flat Bar per; 5005 H111, ISO AlMg1, DIN AlMg1, WNR 3.3315, UNS A95005, ASTM B211
Cold Drawn Tubes per; 5005 H111, ISO AlMg1, DIN AlMg1, WNR 3.3315, UNS A95005, ASTM B210
Extruded Round/Flat Bar and Tubes; 5005 H111, ISO AlMg1, DIN AlMg1, WNR 3.3315, UNS A95005, ASTM B221
Choosing Factors for 5005 H111
- Strength: Low
- Machining: Poor
- Weldability: Excellent
- Formability: Okay
- Corrosion Resistance: Excellent
- Heat Treating: None
Some Well-Known Applications for 5005 H111
In aluminum beverage cans,
In electrical conductor wires,
It is also used in cooking, kitchen utensils.
SUPPLIED FORMS
5005 H111 is produced/supplied in the sheet, tube/profile, round/flat bar forms.
- Sheet
- Round/Flat Bar
- Tube/Profile
