6026
Cold Drawn/Finished (CF) / AlMg2.5SiMnCu (Soğ.Çekim) / 6026 / T8
| Chemical Properties | % Value |
| Silicon (Si) | 0,60 - 1,40 |
| Chromium (Cr) | 0,00 - 0,30 |
| Manganese (Mn) | 0,20 - 1,00 |
| Magnesium (Mg) | 0,60 - 1,20 |
| Copper (Cu) | 0,20 - 0,50 |
| Titanium (Ti) | 0,00 - 0,20 |
| Iron (Fe) | 0,00 - 0,70 |
| Zinc (Zn) | 0,00 - 0,30 |
| Aluminium (Al) | Balance |
| Physical Properties | Value |
| Density | 2.72 g/cm³ |
| Melting Point | 582 °C |
| Thermal Expansion | 23.4 µm/m.°C |
| Modulus of Elasticity | 69 GPa |
| Thermal Conductivity | 172 W/m.K |
| Electrical Resistivity | 0.039 Ωmm² /m |
| Mechanical Properties | Value |
| Proof Strength | 315 MPa |
| Yield Strength | 345 MPa |
| Shear Strength | 260 MPa |
| Elongation A50 mm | 4% |
| Hardness | 95 HB |
6026 aluminum alloy, which has excellent corrosion resistance and is suitable for anodizing, does not contain tin (Sn) element, as it is known for causing cracking in processed parts at high pressure and temperature. Developed meeting the following norms and directives of the European Union as an alternative alloy to 6061 and 6082, the extrusion bars of 6026 alloy also have the same minimum tensile strength value as 2011 and 2030 alloys.
ALLOY DESIGNATIONS
6026 T8 has the following standard designations and specifications.
Cold Drawn Round/Flat Bars per; 6026 T8, 2000/53/CE-ELV (Otomotiv için), 2002/95/CE-RoHS, ASTM B211, UNS A96026
Choosing Factors for 6026 T8
- Strength: Moderate
- Machining: Excellent
- Weldability: Okay
- Formability: Okay
- Corrosion Resistance: Fair
- Heat Treating: Yes
Some Well-Known Applications for 6026 T8
In oleohydraulics,
In the defence industry,
It is also used in machined hot forgings.
SUPPLIED FORMS
6026 T8 is produced/supplied in plate/sheet round/flat bar and tube/profile forms.
- Rod / Round Bar / Flat Bar
- Tube/Profile
