6351
ASTM B221 / AlSi1Mg0.5Mn / 6351 / T4
| Chemical Properties | % Value |
| Silicon (Si) | 0,70 - 1,30 |
| Chromium (Cr) | 0,04 - 0,35 |
| Manganese (Mn) | 0,40 - 0,80 |
| Magnesium (Mg) | 0,40 - 0,80 |
| Copper (Cu) | 0,00 - 0,20 |
| Titanium (Ti) | 0,00 - 0,20 |
| Iron (Fe) | 0,00 - 0,50 |
| Zinc (Zn) | 0,00 - 0,20 |
| Aluminium (Al) | Balance |
| Physical Properties | Value |
| Density | 2,70 g/cm³ |
| Melting Point | 582 °C |
| Thermal Expansion | 23.4 µm/m.°C |
| Modulus of Elasticity | 69 GPa |
| Thermal Conductivity | 170 W/m.K |
| Electrical Resistivity | 46 % IACS |
| Mechanical Properties | Value |
| Proof Strength | 152 MPa |
| Yield Strength | 248 MPa |
| Shear Strength | 150 MPa |
| Elongation A50 mm | 18% |
| Hardness | 67 HB |
6351 alloy is a mid-strength aluminum alloy widely used in machine and aerospace industry.
ALLOY DESIGNATIONS
6351 T4 has the following standard designations and specifications.
Extruded Round/Flat Bar and Tubes per; 6351 T4, ISO AlSi1Mg0.5Mn, UNS A96351, AFNOR A-SGM0.7
Choosing Factors for 6351 T4
- Strength: Mediocre
- Machining: Fair
- Weldability: Excellent
- Formability: Very good
- Corrosion Resistance: Excellent
- Heat Treating: Yes
Some Well-Known Applications for 6351 T4
In marine and defense industries,
It is used in the transportation industry,
It is also used as components of cranes and bridges.
SUPPLIED FORMS
6351 T4 is produced/supplied in round/flat bar and tube/profile forms.
- Rod / Round Bar / Flat Bar
- Tube/Profile
DELIVERY:
