2007

Cold Drawn/Finished (CF) / AlCu4PbMgMn (Soğuk Çekim) / 2007 / T3510

化学性质 % 值
Silicon (Si)0,00 - 0,80
Copper (Cu)3,30 - 4,60
Lead (Pb)0,80 - 1,50
Iron (Fe)0,00 - 0,80
Zinc (Zn)0,00 - 0,80
Nickel (Ni)0,00 - 0,20
Aluminium (Al)Balance
Magnesium (Mg)0,40 - 1,80
Manganese (Mn)0,50 - 1,00
物理特性
Density2.82 g/cm³
Melting Point510 °C
Thermal Expansion23.0 µm/m.°C
Modulus of Elasticity70 GPa
Thermal Conductivity130 W/m.K
Electrical Resistivity%47 IACS
机械性能
Proof Strength270 MPa
Yield Strength410 MPa
Shear Strength240 MPa
Elongation A50 mm5.6%
Hardness72 HB

The cold-drawn 2007 T3510 aluminum alloy stands out for its high strength and light weight. This alloy is commonly used in demanding industrial applications such as automotive, aerospace, and marine industries. Its key properties include high mechanical strength, corrosion resistance, and vibration durability. Additionally, it is suitable for anodizing, which provides aesthetically pleasing and durable surfaces. It also offers good workability for bending and shaping.

The 2007 T3510 alloy has medium weldability and may require special techniques. Its corrosion resistance makes it ideal for environments exposed to seawater and moisture. However, it shows limited resistance to high temperatures, and care should be taken during welding processes.

Overall, this alloy is an ideal choice for industrial applications due to its durability, lightness, corrosion resistance, and workability. However, attention should be paid to its weldability and temperature resistance.



ALLOY DESIGNATIONS

2007 T3510 has the following standard designations and specifications.

Cold Drawn Tubes per; 2007 T3510, WNR 3.1645, DIN AlCuMgPb, AFNOR A-U4Pb, UNI 9002/8, UNE L-3121, UNS A92007, ISO AlCu4PbMgMn, ASTM B210



Choosing Factors for 2007 T3510

  • Strength: High
  • Machining: Okay
  • Weldability: Weak
  • Formability: Low
  • Corrosion Resistance: Poor
  • Heat Treating: Yes


Some Well-Known Applications for 2007 T3510

In the automotive industry,

As components of military equipments,

It is also used in AC units and heat exchangers



SUPPLIED FORMS

2007 T3510 is produced/supplied in round/flat bar and tube/profile forms.
  • Tube
交货:
