Barres Étirées à Froid
Tubes Étirés à Froid
2014
Cold Drawn/Finished (CF) / AlCu4SiMg (Soğuk Çekim) / 2014 / T3510
Chemical Properties | % Value |
Silicon (Si) | 0,50 - 1,20 |
Chromium (Cr) | 0,00 - 0,10 |
Manganese (Mn) | 0,40 - 1,20 |
Magnesium (Mg) | 0,20 - 0,80 |
Copper (Cu) | 3,90 - 5,00 |
Titanium (Ti) | 0,00 - 0,15 |
Iron (Fe) | 0,00 - 0,70 |
Zinc (Zn) | 0,00 - 0,25 |
Aluminium (Al) | Balance |
Physical Properties | Value |
Density | 2.80 g/cm³ |
Melting Point | 507 °C |
Thermal Expansion | 22.7 µm/m.°C |
Modulus of Elasticity | 73 GPa |
Thermal Conductivity | 130 W/m.K |
Electrical Resistivity | %34 IACS |
Mechanical Properties | Value |
Proof Strength | 320 MPa |
Yield Strength | 430 MPa |
Shear Strength | 250 MPa |
Elongation A50 mm | 7% |
Hardness | 100 HB |
ALLOY DESIGNATIONS
2014 T3510 has the following standard designations and specifications.
As Cold Drawn Tube: 2014 T3510, ASTM B211, UNS A92014, ASTM B928, WNR 3.1255, ISO AlCu4SiMg
Choosing Factors for 2014 T3510
- Strength: Very good
- Machining: Great
- Weldability: Low
- Formability: Good
- Corrosion Resistance: Weak
- Heat Treating: Yes
Some Well-Known Applications for 2014 T3510
In irrigation tubing and pipelines,
It is also used in the automotive industry.
SUPPLIED FORMS
2014 T3510 is produced/supplied in tube/profile forms.
- Tube/Profile
DELIVERY:
