7010
AMS 4203 / AlZn6MgCu / 7010 / T7351
Chemical Properties | % Value |
Silicon (Si) | 0,00 - 0,12 |
Chromium (Cr) | 0,00 - 0,05 |
Manganese (Mn) | 0,00 - 0,10 |
Magnesium (Mg) | 2,10 - 2,60 |
Copper (Cu) | 1,50 - 2,00 |
Titanium (Ti) | 0,00 - 0,06 |
Iron (Fe) | 0,00 - 0,15 |
Zinc (Zn) | 5,70 - 6,70 |
Aluminium (Al) | Balance |
Titanium + Zirconium (Ti+Zr) | 0,10 - 0,16 |
Physical Properties | Value |
Density | 2.81 g/cm³ |
Melting Point | 475 °C |
Thermal Expansion | 23.7 µm/m.°C |
Modulus of Elasticity | 71 GPa |
Thermal Conductivity | 150 W/m.K |
Electrical Resistivity | %40 IACS |
Mechanical Properties | Value |
Proof Strength | 420 MPa |
Yield Strength | 520 MPa |
Shear Strength | 300 MPa |
Elongation A50 mm | 7% |
Hardness | 85 HB |
ALLOY DESIGNATIONS
7010 T7351 has the following standard designations and specifications.
Plates per; 7010 T7351, AMS 4203, ISO AlZn6MgCu, WNR 3.4394, UNS A97010
Choosing Factors for 7010 T7351
- Strength: Very good
- Machining: Good
- Weldability: Poor
- Formability: Poor
- Corrosion Resistance: Excellent
- Heat Treating: Yes
Some Well-Known Applications for 7010 T7351
It is used primarily in the aerospace industry,
Aircraft fuselage and wing parts,
It is also used in the nuclear industry.
SUPPLIED FORMS
7010 T7351 is produced/supplied in the plate form.
- Plate
