1050
ASTM B211 / Al99.5 / 1050 / O
| Chemical Properties | % Value |
| Silicon (Si) | 0,00 - 0,25 |
| Manganese (Mn) | 0,00 - 0,05 |
| Magnesium (Mg) | 0,00 - 0,05 |
| Copper (Cu) | 0,00 - 0,05 |
| Titanium (Ti) | 0,00 - 0,03 |
| Iron (Fe) | 0,00 - 0,40 |
| Zinc (Zn) | 0,00 - 0,05 |
| Aluminium (Al) | Balance |
| Physical Properties | Value |
| Density | 2.705 g/cm³ |
| Melting Point | 646 °C |
| Thermal Expansion | 23.6 µm/m.°C |
| Modulus of Elasticity | 73 GPa |
| Thermal Conductivity | 155 W/m.K |
| Electrical Resistivity | %40 IACS |
| Mechanical Properties | Value |
| Proof Strength | 28 MPa |
| Yield Strength | 78 MPa |
| Shear Strength | 62 MPa |
| Elongation A50 mm | %39 |
| Hardness | 21 |
Aluminium alloy 1050 O plate is a popular grade of aluminium for general sheet metal work where moderate strength is required. It is used in aerospace and also many other applications :
ALLOY DESIGNATIONS
1050 O has the following standard designations and specifications.
Sheets per; 1050 O, ASTM B209, L-3051, UNS A91050, WNR 3.0255, ISO Al99.5, BS 1B
Extruded Round/Flat Bar, Wire and Tubes per; 1050 O, ASTM B221, ASTM B491, WNR 3.0255, ISO Al99.5
Cold Drawn Round/Flat Bar, Wire and Tubes per; 1050 O, ASTM B211, WNR 3.0255, ISO Al99.5
Choosing Factors for 1050 O
- Strength: Moderate
- Machining: Poor
- Weldability: Very good
- Formability: Good
- Corrosion Resistance: Very good
- Heat Treating: Yes
Some Well-Known Applications for 1050 O
It is used in chemical process plant equipment,
In heat sinks in the automotive industry,
It is also used in cable sheathing materials.
SUPPLIED FORMS
1050 O is produced/supplied in sheet, round/flat bar and tube/profile forms.
- Sheet
- Round/Flat Bar
- Tube/Profile
