2014 clad
AMS QQ-A-250/3 / AlCu4SiMg / 2014 clad / T4
Chemical Properties | % Value |
Silicon (Si) | 0,5 - 1,2 |
Chromium (Cr) | 0,00 - 0,10 |
Manganese (Mn) | 0,40 - 1,20 |
Magnesium (Mg) | 0,20 - 0,80 |
Copper (Cu) | 3,90 - 5,00 |
Titanium (Ti) | 0,00 - 0,15 / 0,00 - 0,20 |
Iron (Fe) | 0,00 - 0,7 |
Zinc (Zn) | 0,00 - 0,25 |
Aluminium (Al) | Balance |
Physical Properties | Value |
Density | 2.8 g/cm³ |
Melting Point | 507 °C |
Thermal Expansion | 22.7 µm/m.°C |
Modulus of Elasticity | 73 GPa |
Thermal Conductivity | 150 W/m.K |
Electrical Resistivity | 40 % IACS |
Mechanical Properties | Value |
Proof Strength | 270 MPa |
Yield Strength | 421 MPa |
Shear Strength | 260 MPa |
Elongation A50 mm | 14 % |
Hardness | 110 HB |
ALLOY DESIGNATIONS
2014 T4 clad has the following standard designations and specifications.
As Alclad sheet; 2014 T4 clad, AMS QQ-A-250/3, ASTM B209, ISO AlCu4SiMg, UNS A92014, AIR 9048.070, EN 2088, BS L 164, WNR 3.1255
Choosing Factors for 2014 T4 clad
- Strength: Great
- Machining: Very good
- Weldability: Poor
- Formability: Okay
- Corrosion Resistance: Poor
- Heat Treating: Yes
Some Well-Known Applications for 2014 T4 clad
In the automotive industry and defense industry,
In military vehicles and hydraulic applications,
In addition to being used in the aerospace sector, it is also used in pipelines.
SUPPLIED FORMS
2014 T4 clad is produced/supplied in sheet form.
- Sheet
