5182
ASTM B209 / AlMg4.5Mn0.4 / 5182 / H111
| Chemical Properties | % Value |
| Silicon (Si) | 0,00 - 0,25 |
| Chromium (Cr) | 0,15 - 0,35 |
| Manganese (Mn) | 0,00 - 0,10 |
| Magnesium (Mg) | 3,10 - 3,90 |
| Copper (Cu) | 0,00 - 0,10 |
| Titanium (Ti) | 0,00 - 0,20 |
| Iron (Fe) | 0,00 - 0,40 |
| Zinc (Zn) | 0,00 - 0,20 |
| Aluminium (Al) | Balance |
| Physical Properties | Value |
| Density | 2,66 g/cm³ |
| Melting Point | 595 °C |
| Thermal Expansion | 23.8 µm/m-°C |
| Modulus of Elasticity | 69 GPa |
| Thermal Conductivity | 130 W/m.K |
| Electrical Resistivity | %32 IACS |
| Mechanical Properties | Value |
| Proof Strength | 130 MPa |
| Yield Strength | 280 MPa |
| Shear Strength | 170 MPa |
| Elongation A50 mm | %14 |
| Hardness | 69 HB |
5182 H111 aluminum alloy is known for its high corrosion resistance, good machinability, and medium-level strength. Belonging to the aluminum-magnesium alloy class, this material is widely used in marine, automotive, construction, and other industrial applications exposed to harsh environmental conditions. The H111 temper gives the alloy medium hardness through cold working, which increases durability while maintaining flexibility. Its lightweight and strong structure make it an ideal material for marine and outdoor applications.
5182 H111 aluminum alloy is highly suitable for anodizing. Anodizing forms a protective oxide layer on the alloy surface, enhancing corrosion resistance and providing an aesthetic appearance. This feature is particularly advantageous in outdoor and marine applications. In terms of weldability, 5182 H111 aluminum alloy performs well. Being an aluminum-magnesium alloy, it can be reliably welded using appropriate welding techniques.
In terms of bending and forming, 5182 H111 aluminum alloy is quite flexible and workable. Despite being cold-worked, it can be easily shaped and bent successfully with the right processing techniques. This allows the production of complex shapes in industries such as automotive, construction, and marine. Additionally, 5182 H111 alloy can be safely used in high-vibration environments. Its high durability and elastic modulus make it suitable for engine parts, transport equipment, and other vibration-exposed components.
Regarding corrosion resistance, 5182 H111 aluminum alloy shows high resistance to harsh conditions such as seawater and humid environments. This makes the 5182 H111 alloy an ideal material for equipment used in marine and other moist environments. Advantages include high corrosion resistance, good machinability, and light weight, while disadvantages include limited resistance to high temperatures and limited performance in certain strength-critical applications.
MATERIAL COMPOSITION STANDARDS
5182 H111 can be found in the following standards:
• 5182 H111 Sheet; ISO AlMg4.5Mn0.4, DIN AlMg5Mn, WNR 3.3549, UNS A95182, ASTM B209
• 5182 H111 Plate; ISO AlMg4.5Mn0.4, DIN AlMg5Mn, WNR 3.3549, UNS A95182, ASTM B209
Characteristic Properties of 5182 H111:
- Strength: Medium
- Machinability: Very good
- Weldability: Good
- Formability: Good
- Corrosion Resistance: Very good
- Heat Treatment: No
Well-Known Applications for 5182 H111:
Used in structural and interior panels in the automotive industry,
Aluminum tinplate cans,
Various applications including flanges and other components.
STOCK
We supply 5182 H111 in sheet/plate form.
