2014A
ASTM B928 / AlCu4SiMg / 2014A / T3510/ T3511
| 化学性质 | % 值 |
| Silicon (Si) | 0,50 - 1,20 |
| Chromium (Cr) | 0,00 - 0,10 |
| Manganese (Mn) | 0,40 - 1,20 |
| Magnesium (Mg) | 0,20 - 0,80 |
| Copper (Cu) | 3,90 - 5,00 |
| Titanium (Ti) | 0,00 - 0,15 |
| Iron (Fe) | 0,00 - 0,70 |
| Zinc (Zn) | 0,00 - 0,25 |
| Aluminium (Al) | Balance |
| 物理特性 | 值 |
| Density | 2.80 g/cm³ |
| Melting Point | 507 °C |
| Thermal Expansion | 22.7 µm/m.°C |
| Modulus of Elasticity | 73 GPa |
| Thermal Conductivity | 130 W/m.K |
| Electrical Resistivity | %34 IACS |
| 机械性能 | 值 |
| Proof Strength | 320 MPa |
| Yield Strength | 430 MPa |
| Shear Strength | 250 MPa |
| Elongation A50 mm | 7% |
| Hardness | 100 HB |
2014A T3510/T3511 aluminum exhibits high strength and is widely used in aerospace applications.
ALLOY DESIGNATIONS
2014A T3510/T3511 has the following standard designations and specifications.
As Cold Drawn Tube: 2014A T3510/ T3511, ASTM B211, UNS A92014, ASTM B928, WNR 3.1255, ISO AlCu4SiMg
Choosing Factors for 2014A T3510/T3511
- Strength: Very good
- Machining: Great
- Weldability: Bad
- Formability: Okay
- Corrosion Resistance: Weak
- Heat Treating: Yes
Some Well-Known Applications for 2014A T3510/T3511
Mainly in the aerospace sector and defense industry,
In the production of military vehicles and weapons,
It is also used in pipelines and the automotive industry.
SUPPLIED FORMS
2014A T3510/ T3511 is produced/supplied in tube/profile forms.
- Tube/Profile
