7050
AMS 4107 / AlZn6CuMgZr / 7050 / T74
| Chemical Properties | % Value |
| Silicon (Si) | 0,00 - 0,12 |
| Chromium (Cr) | 0,00 - 0,04 |
| Manganese (Mn) | 0,00 - 0,10 |
| Magnesium (Mg) | 1,90 - 2,60 |
| Copper (Cu) | 2,00 - 2,60 |
| Titanium (Ti) | 0,08 - 0,21 |
| Iron (Fe) | 0,00 - 0,15 |
| Zinc (Zn) | 5,70 - 6,70 |
| Aluminium (Al) | Balance |
| Physical Properties | Value |
| Density | 2,83 g/cm³ |
| Melting Point | 488 °C |
| Thermal Expansion | 22.1 µm/m.°C |
| Modulus of Elasticity | 71 GPa |
| Thermal Conductivity | 140 W/m.K |
| Electrical Resistivity | 35 % IACS |
| Mechanical Properties | Value |
| Proof Strength | 440 MPa |
| Yield Strength | 530 MPa |
| Shear Strength | 310 MPa |
| Elongation A50 mm | %8 |
| Hardness | 150 HB |
A high strength aerospace aluminium alloy with good resistance to stress-corrosion cracking.
TEMPER TYPES
Alloy AMS 4050 plate is supplied in temper T7451
- T651
- T451
SUPPLIED FORMS
Alloy AMS 4050 in temper T7451 is supplied as Plate
- Bar
- Extrusions
- Tube
MECHANICAL PROPERTIES
These Mechanical Properties are for AMS 4050 Plate in the T7451 temper
DELIVERY:
