7050
AMS 4107 / AlZn6CuMgZr / 7050 / T74
| Chemical Properties | % Value |
| Silicon (Si) | 0,00 - 0,12 |
| Chromium (Cr) | 0,00 - 0,04 |
| Manganese (Mn) | 0,00 - 0,10 |
| Magnesium (Mg) | 1,90 - 2,60 |
| Copper (Cu) | 2,00 - 2,60 |
| Titanium (Ti) | 0,08 - 0,21 |
| Iron (Fe) | 0,00 - 0,15 |
| Zinc (Zn) | 5,70 - 6,70 |
| Aluminium (Al) | Balance |
| Physical Properties | Value |
| Density | 2,83 g/cm³ |
| Melting Point | 488 °C |
| Thermal Expansion | 22.1 µm/m.°C |
| Modulus of Elasticity | 71 GPa |
| Thermal Conductivity | 140 W/m.K |
| Electrical Resistivity | 35 % IACS |
| Mechanical Properties | Value |
| Proof Strength | 440 MPa |
| Yield Strength | 530 MPa |
| Shear Strength | 310 MPa |
| Elongation A50 mm | %8 |
| Hardness | 150 HB |
This alloy is used in aircraft structural parts. The alloy has characteristics of high strength coupled with good resistance to exfoliation and stress corrosion cracking. The alloy also has good fracture toughness and fatigue resistance. Aluminum alloy 7050 is the premier choice for aerospace applications requiring the best combination of strength, stress corrosion cracking (SCC) resistance and toughness.
ALLOY DESIGNATIONS
Aluminium alloy EN AW 7050 has similarities to the following standard designations and specifications ;
Alloy 7050 UNS A97050 ASTM B209
DIN AlZn6MgCuZr
TEMPER TYPES
7050 is supplied in a wide range of tempers:
- T73511 - Solution heat-treated, stress-relieved by controlled stretching (permanent set 1% to 3% for extruded rod, bar, shapes and tube, 0.5% to 3% for drawn tube) and then artificially overaged in order to achieve the best stress corrosion resistance. The products receive no further straightening after stretching, except that minor straightening is allowed after stretching to comply with standard tolerances.
- T7451 - Solution heat-treated, stress-relieved by controlled stretching and then artificially overaged (between T73 and T76). The products receive no further straightening after stretching.
- T74511 - Solution heat-treated, stress-relieved by controlled stretching and then artificially overaged (between T73 and T76). The pro-ducts receive no further straightening after stretching, except that minor straightening is allowed after stretching to comply with standard tolerances.
- T76 - Solution heat-treated and then artificially overaged in order to achieve a good exfoliation corrosion resistance.
- T762 - Solution heat-treated and then artificially overaged in order to achieve a good exfoliation corrosion resistan-ce. Applies to test material heat-treated from annealed or F temper or to products heat-treated from any tem-per by the user.
- T7651 - Solution heat-treated, stress-relieved by controlled stretching and then artificially overaged in order to achieve a good exfoliation corrosion resistance. The products recieve no further straightening after stretching.
- T76511 - Solution heat-treated, stress-relieved by controlled stretching and then artificially overaged in order to achieve a good exfoli-ation corrosion resistance. The products receive no further straightening after stretching, except that minor straightening is allowed after stretching to comply with standard tolerances.
SUPPLIED FORMS
7050 is supplied in plate, sheet, bar and extrusions.
- Plate
- Sheet
- Round Bar / Bar
- Tube / Extrusions
