1050 / 1050A

BS 1B / Al99.5 / 1050 / 1050A / O

Chemical Properties % Value
Silicon (Si)0,00 - 0,25
Manganese (Mn)0,00 - 0,05
Magnesium (Mg)0,00 - 0,05
Copper (Cu)0,00 - 0,05
Titanium (Ti)0,00 - 0,03 / -
Iron (Fe)0,00 - 0,40
Zinc (Zn)0,00 - 0,05
Aluminium (Al)Balance
Physical Properties Value
Density2.705 g/cm³
Melting Point646 °C
Thermal Expansion23.6 x 10^-6 /K
Modulus of Elasticity73 GPa
Thermal Conductivity155 W/m.K
Electrical Resistivity%40 IACS
Mechanical Properties Value
Proof Strength28 MPa
Yield Strength78 MPa
Shear Strength51 MPa
Elongation A50 mm%39
Modulus of Elasticity69 GPa

High strength structural components for aircraft , military vehicles and bridges, weapons manufacture, structural applications.



ALLOY DESIGNATIONS

Aluminium alloy 2014 / 2014A is covered by Standard BS EN 2100 and has similarities to the following standard designations and specifications:

2014 / 2014A ,  AMS 4029,   ISO AlCu4SiMg,  DIN AlCuSiMn,  UNS A92014,  BS L93



TEMPER TYPES

The most common tempers for 2014 / 2014A aluminium are:

  • O   - Soft
  • T3 - Solution heat treated, cold worked and naturally aged
  • T4 - Solution heat treated and naturaly aged to a substantially stable condition
  • T6 - Solution heat treated and artificially aged
  • T651 - Solution heat treated, stress relieved by stretching then artificially aged



SUPPLIED FORMS

AMS 4029 aluminium is supplied in Plate.

  • Plate
