7075
Cold Drawn/Finished (CF) / AlZn5.5MgCu (Soğuk Çekim) / 7075 / T73511
| Chemical Properties | % Value |
| Silicon (Si) | 0,00 - 0,40 |
| Chromium (Cr) | 0,18 - 0,28 |
| Manganese (Mn) | 0,00 - 0,30 |
| Magnesium (Mg) | 2,10 - 2,90 |
| Copper (Cu) | 1,20 - 2,00 |
| Titanium (Ti) | 0,00 - 0,20 |
| Iron (Fe) | 0,00 - 0,50 |
| Zinc (Zn) | 5,10 - 6,10 |
| Aluminium (Al) | Balance |
| Physical Properties | Value |
| Density | 2.81 g/cm³ |
| Melting Point | 477°C |
| Thermal Expansion | 23 µm/m.°C |
| Modulus of Elasticity | 72 GPa |
| Thermal Conductivity | 155 W/m.K |
| Electrical Resistivity | %33 IACS |
| Mechanical Properties | Value |
| Proof Strength | 420 MPa |
| Yield Strength | 513 MPa |
| Shear Strength | 303 MPa |
| Elongation A50 mm | %8 |
| Hardness | 135 HB |
7075 T73511 is an aluminum alloy preffered frequently for high strength pipes and rods. Both internal stress is removed and tensile corrosion resistance is high.It is preferred in high sensitivity and strength values projects, It is a high cost aluminum material because of its production process. As Referans Metal, we are intensively supplying this material as rod forms in large diameters and pipe forms in small diameters.
ALLOY DESIGNATIONS
7075 T73511 has similarities to the following standard designations and specifications ;
Extrusion Rod, Flat Bar, Pipe, Profile as; 7075 T73511, AMS QQ-A-200/11,
AMS 4167, ASTM B221, EN 2127, EN 2632, EN 2315
BS 2 L160
Choosing Factors for 7075 T73511:
- Strength: Fair
- Machining: Moderate
- Weldability: Weak
- Formability: Low
- Corrosion Resistance: Significant
- Heat Treating:Yes
TEMPER TYPES
BS L160 7075 is supplied in the following heat treatment types:
- T73510
- T73511
Some Well-Known Applications for 7075 T73511:
For high precision automotive parts,
Aircraft engines
As connection apparatus in aircrafts.
SUPPLIED FORMS
7075 T73511 is supplied in rod / round bar / flat bar and tube / extrusion / profile form.
- Rod / Round Bar / Flat Bar
- Tube / Extrusions / Profile
